Digital Storage Oscilloscopes Tout High Bandwidth, Sample Rate

Testing, accurate, fast, and deep, is critical for the development of solutions using the latest technologies. it is no longer possible (in a serious fashion) to create a systems and field it without thoroughly testing it under a variety of situations. Developed to address these needs in a cost-effective manner to address the needs of both engineers and educators, Tektronix released the TBS2000B Series of Digital Storage Oscilloscopes. The TBS2000B scopes extend the performance of the TBS2000 portfolio to 200 Mhz with 2GS/s maximum sample rate.

Designed for easy operation, the oscilloscopes have a 9-inch display with 15 horizontal divisions, for more time per screen, and a 5M record length to capture long time windows. Their 200-MHz bandwidth, and 2GS/s sample rate captures more signal to debug and validate designs faster. Offering a TekVPI probe interface, the 'scopes support a wide range of active, differential, and current probes with automatic scaling and units. On-waveform cursor readouts with search and mark features enable easy identification of events that occur in the acquired waveform.

Device interfaces include Wi-Fi support (via USB Wi-Fi dongle), 2 USB host ports, and 100-BaseT Ethernet. Compatibile with existing designs, the TBS2000B series is a drop-in replacement for TBS2000 series oscilloscopes, with the same form factor and programmable interface. Available now, the suite of TBS2000B modules are priced from US$1,370.00.

TBS2000B

Tektronix
