Flash in the 3D Pan

Aug. 14, 2015
Storage vendors were showing off their latest wares at the Flash Memory Summit. This includes devices like Samsung’s 3D, 48-layer V-NAND chip that packs in 256-Gbytes of 3-bit multi-level-cell (MLC) flash memory.

1. Samsung’s 3D, 48 layer V-NAND chip (a) packs in 256-Gbits of 3-bit multi-level-cell (MLC) flash memory. Toshiba’s 48-layer, BiCS device (b) also uses 3-bit MLC and delivers 256-Gbits of storage.

Storage vendors were showing off their latest wares at the Flash Memory Summit. This includes devices like Samsung’s 3D, 48-layer V-NAND chip [Fig. 1(a)] that packs in 256 Gbits of 3-bit multi-level-cell (MLC) flash memory. That is 32 Gbytes on a single chip. Not to be outdone, Toshiba’s BiCS 48-layer, 3-bit MLC flash chip [Fig. 1(b)] also has 256 Gbits of storage. Samsung’s cell uses a 3D Charge Trap Flash (CTF) structure.

Also be sure to check out our gallery coverage of the event, here.

Toshiba also announced a 16-layer NAND flash device that uses Through Silicon Via (TSV) technology. This allows the chip to transfer data at rates in excess of 1 Gibt/s. The approach also cuts power requirements in half by reducing core voltage to 1.8 V and I/O to 1.2 V. While the 48-layer devices will provide high capacity, the TSV chips deliver low latency and high bandwidth and the chips have a high IOPS/W.

Riccardo Badalone’s, chief executive officer and co-founder of Diablo Technologies, kicked off the conference with his keynote, “Disruptive Memory Technology Enables New In-Memory Applications.” Of course, he was talking about Diablo Technologies’ new DDR4 Memory1 DIMM (Fig. 2). Memory1 DIMMs are available with capacities up to 256 Gbytes. That is four times the storage available in DRAM DIMMs and the flash memory is on the memory channel, not the PCI Express bus (see "Memory Channel Flash Storage Provides Fast RAM Mirroring").

2. Diablo Technologies’ all-flash Memory1 DIMM finds a home in a DDR4 memory slot.

Seagate was touting its PCIe Gen 3, NVMe support with its Nytro XF1440 2.5-in and Nytro XM1440 M.2 SSDs that deliver 25,000 IOPS/W. The hot swappable drives use a SFF-8639 connector and have a maximum capacity of 1.8 Tbytes while the M.2 devices support up to 960 Gybtes. Self-Encrypting Drives (SEDs) are available.

There was discussion of Intel and Micron’s XPoint 3D storage and Altera was demonstrating its NAND Flash reference design that can extend the life of flash memory up to 7 times. The reference design used an Arria 10 SoC and implemented Mobiveil's Universal NVM Express Controller (UNEX).

There was never a dull moment at Flash Memory in Santa Clara.
