What you’ll learn:
- Potential sources of RF coupling.
- How to cut some of the coupling sources.
- Best practice design to create a system that’s immune to coupling.
Wireless system-on-chip (SoC) designs require implementing all circuit domains on the same die. This enables manufacturers to reduce cost and support integrity. On the other hand, crosstalk between these domains can be problematic and degrade the overall performance.
Electromagnetic interference (EMI) is caused by radiated radio-frequency (RF) signals. Various techniques are available to lower EMI in system design. For instance, radiated RF can be addressed with filtering and shielding; however, this doesn’t mitigate on-chip RF coupling.
Channels for RF Coupling
RF coupling is an example of crosstalk between the RF domain and other domains (Fig. 1). Wireless transmitters are required to generate output power in the range of ~10 dBm. Power amplifiers (PAs) generate these levels of power while sometimes incorporating on-chip inductors or transformers.
Due to electromagnetic radiation of the inductors, a fraction of the transmitted power can couple to other domains inside the SoC. Whether the coupled component is at the same transmitted frequency or its harmonics, it degrades transceiver performance. This becomes evident when the output signal spectrum of the integrated frequency synthesizer becomes spurious.
The same coupling mechanism can happen outside the SoC on the PCB level, where the antenna will radiate and impact critical PCB routes of other domains near to it (Fig. 2).
Reducing RF Coupling
Generally, any block that operates at an arbitrary frequency (f1) is considered an aggressor for a victim block that operates at another frequency (f2) and vice versa. There can be exceptions when one frequency is an exact integer multiple of the other.
>>Download the PDF of this article
The links through which the aggressors affect victims include:
- Supply networks
- Parasitic capacitive coupling
- Parasitic magnetic coupling
- Substrate coupling
Reduction of Supply Network Coupling
Different regulators can be used to decrease coupling through supply networks. Consider an aggressor block that’s insensitive to supply noise. Such a block should be supplied from a shunt regulator,1 like that in Figure 3a. The reverse power-supply rejection ratio (PSRR), which is the signal transfer function from the regulator output to its supply, is small.
Similarly, sensitive blocks to supply noise, which have negligible contribution to supply contamination, should be supplied from series regulators1 (Fig. 3b). Forward PSRR, which is the transfer of supply noise to the regulator output, is small in series regulators.
Another common way to decrease coupling through supply networks is by adding an ample capacitance of supply decoupling capacitors near each block. However, this must be done carefully to maximize the range of frequencies in which the decoupling capacitors are effective.
Parasitic resistance of the decoupling capacitor routing should be minimized to increase its quality factor. When the decoupling capacitors are realized by MOS devices, the length of the unit decoupling capacitors should be minimized to decrease its channel resistance.2 Impedance of a capacitor in series with a parasitic resistor saturates at the parasitic resistance value at high frequencies (Fig. 4).
One infrequently used technique to mitigate supply network coupling is to add passive or active supply filters.1 Design engineers may initially reject this idea as there’s an associated loss of supply voltage headroom. However, consider a block that has a 1-V supply and consumes 0.5 mA (Fig. 5).
Insertion of a 100-Ω resistor decreases the supply headroom by just 50 mV. When the added filter capacitance is 16 pF, supply noise at 1 GHz gets attenuated by 20 dB. A similar argument can be made for the area-efficient active filter utilizing a native NMOS device (Fig. 6).
Finally, separating ground connections of different blocks and connecting them to different pads may lead to severe issues.3 Separation can contaminate sensitive blocks instead of isolating them. This counter-intuitive mechanism is illustrated in Figure 7.
Reduction of Parasitic Capacitive Coupling
Parasitic capacitive coupling is handled on the layout level. Sensitive and noisy nodes should be shielded with their reference supply rails. Ground plane design can help as well.
Capacitance is inversely proportional to distance between conductors; therefore, increasing spacing between traces will help.
Reduction of Parasitic Magnetic Coupling
Long routes can be magnetically coupled to each other when they have the same orientation. This effect is more pronounced when coupling occurs between a long parallel route to one side of a spiral coil (Fig. 8). The situation worsens when the coil carries currents of both high frequencies and large magnitude, as in the case of power amplifiers.
To diminish this magnetic coupling, sensitive routes should be as far as possible from coils and other noisy routes. Also, when routes are orthogonal to each other, magnetic coupling decreases substantially.
Reduction of Substrate Coupling
Sometimes noise coupling can occur through the substrate. To overcome this, different circuits can be isolated into wells using the deep N-well layer. Moreover, the high-resistivity native layer should be added in between the isolated domains, with adjacent bulk ties that provide low-impedance paths to different ground pads.4 This technique is illustrated in Figure 9.
Finally, a couple of guidelines can be followed to further decrease noise transfer from one domain to another. Differential signaling should be used whenever possible for inter-domain connections. This minimizes transfer of the reference node noise. Also, the signal drivers at the boundary of one domain could be deliberately weakened to minimize the electrical transfer of all signals to other domains. This approach is very effective when handling CMOS logic signals, such as high-speed clocks and digital buses.
Don’t Overlook Coupling Reduction Techniques
RF coupling in wireless SoC systems can be a real problem and could degrade overall performance. Special attention should be paid when designing the SoC floorplan and identifying aggressor and victim blocks. Coupling reduction techniques should be implemented to get the required high performance.
