Semtech Corporation announced the SC33020H Load Switch platform in a tiny 0.9mm x 0.9mm, 4 bump Chip Scale Package (CSP) with industry leading Ron of just 32m‡. The product debut was in conjunction with the Applied Power Electronics Conference.
The SC33020H load switch provides power rail control for up to 2A with reverse current blocking protection for both portable and non-portable devices, including wearables, action video cameras, smart phones, tablets and more. Semtech will highlight its new load switch at the APEC. In addition, Andy Khayat, Senior Director for Consumer Power in Semtech's Power Management Group, presented advanced power solutions in Semtech's "Greener, Smarter, Smaller Power Solutions" seminar on Tuesday, March 17.
The switch accepts 1.6V to 5.5V supply input rail and whenever the output voltage goes higher than the input rail the switch blocks current from flowing in reverse direction to protect sensitive upstream circuitry or to prevent excessive power leakage loss in application standby states. The reverse blocking feature is present at all times regardless of the switch ON/OFF state. The Load Switch is ESD-hardened to greater than 4kV for robust circuit protection.
Key Features of SC33020H
- VIN Range: 1.6V to 5.5V
- IOUT: Up to 2A
- Ultra-Low Ron 32mW
- Reverse Current Blocking in ON or OFF state
- 4kV ESD Protection
- Chip Scale Package 0.9mm x 0.9mm x 0.60mm, 4-bumps at 0.5mm pitch
The SC33020H is available immediately in production quantities and is priced at $0.38 each in 5,000-piece reels. The ordering codes are SC33020HCSTRT. Evaluation boards are also available.
