Configurable Power Supplies Produce 1200W In 1U Format

The UltiMod range power supply from Excelsys Technologies provides up to 12 outputs and 1200W in a compact 1U format.  It provides up to 12 fully isolated DC outputs ranging from 1.5 V  to 58 V provided from a range of single and dual output modules (powerMods). The feature-rich powerMods provide a suite of output signals and user configurable functions increasing design-in flexibility. User configurable functions include local and remote output adjustment, adjustable current limit, alternative current limiting techniques and inhibit/enable functions.

The Excelsys UltiMod is simple to configure for any application. Two versions of the AC input front ends (powerPacs) are available to accommodate either 4 (UX4) or 6 (UX6) output modules. The powerPacs carry dual certification: 2xMOPP, EN60601-1 3rd Edition for medical applications and EN60950 for industrial applications. Ultimod units are also SEMI F47 compliant. The UX4 delivers up to 600W, the UX6 up to 1200W.  All UltiMod products can with stand shock >60G, per MIL STD 810G and will start-up at -40 ºC.

Typical price ranges from $275 (600 W - UX4 models) and $500  (1.2 kW - UX6 models).
