A Smart Home Needs Smart Battery Management

2. A prime role of a battery charger is to manage to the charging cycle. (Source: TI Training: “How to select a charger for building automation and home appliances applications?”)

Battery monitoring: Battery-management devices include sophisticated algorithms to monitor and measure the condition of the battery. The amount of energy in the battery is expressed as its state of charge (SoC). This is usually stated as a percentage, from 0% (fully discharged) to 100% (fully charged).  One common algorithm, coulomb counting, estimates the available charge by beginning with a baseline value, then adjusting that value over time as current flows into and out of the battery. The baseline value is reset periodically by measuring the open-circuit voltage (OCV) under a set of tightly specified no-load conditions and deriving the new value from a battery-characterization table.

All batteries slowly degrade over their lifetime based on their operating patterns, environmental conditions, and internal processes. This degradation occurs under all load conditions, and even while in storage.

A battery’s state of health (SoH), expressed as a percentage, is another widely-used metric. SoH indicates a battery’s current performance relative to that of a new part. For example, a battery’s effective capacity may have degraded to 850 mAh after two years compared to 1000 mAh when new—meaning its SoH is 85%. While there are multiple variations, many battery chemistries degrade rapidly once their SoH falls below 70-75%. As a result, once a battery is at 80%, it’s usually time to replace it if the application is safety- or security-critical.

Choosing a Charger for a Primary Battery Application

For a pure battery-powered application, long battery life is essential. The charger must follow the standard charging profile, of course, but precise control of the voltage during the CV phase is critical to longevity. A small difference in charging voltage can make a huge difference.

For example, a battery with a nominal cell voltage of 4.1 V can be overcharged to give a higher initial capacity, but over multiple charging cycles, the degradation is much more severe (Fig. 3). Compare the curves for a 4.25-V versus 4.2-V charging voltage: After 500 charging cycles, a 50-mV difference results in a 50% capacity reduction!

3. The useful life of a battery depends heavily on the CV stage of the charging cycle. (Source: TI Training video by Will Zhou)

Use a Linear Charger for Low-Power Applications

For small batteries and low charge currents, a linear charger is a good choice—it’s cost-effective and easy to implement. The linear topology uses a pass transistor to step down the adapter voltage. This transistor wastes excess power by dissipating it as heat, but that’s not an issue for a low-power application.

Many charge-management devices integrate commonly used power-management functions to save space and reduce bill-of-materials (BOM) costs. The bq25120A, for example, bundles a linear charger, a 300-mA buck converter, a 100-mA low-dropout (LDO) linear regulator, a battery monitor circuit, and other functions into a 25-pin wafer chip-scale package (WCSP) that measures 2.5 × 2.5 mm (Fig. 4).

4. The bq25120A is a highly integrated power-management solution for low-power applications. (Source: TI Semiconductors: BQ25120A)

The battery charger follows the standard Li-ion charge profile. An input is provided for a voltage-based battery-pack thermistor. Internal circuitry monitors the battery temperature and automatically changes the charge parameters to keep the battery within its safe temperature range. This circuit is compatible with the battery-charging safety standards established by the Japan Electronics and Information Technology Industries Association (JEITA).

USB is the most popular serial interface, and residential ac outlets are starting to integrate USB charging capability. The bq25120 is optimized for 5-V USB-derived input power, but can withstand line transients up to 20 V.

The integrated buck converter incorporates TI’s high-efficiency low-ripple DCS control topology with load currents as low as 10 µA. The device features low quiescent current during operation and shutdown for maximum battery life, and supports charge currents from 5 to 300 mA.

The input current limit, charge current, buck-converter output voltage, LDO output voltage, and other parameters are programmable through the industry-standard I²C interface.

Switched-Mode Chargers Suit Higher-Current Applications

A linear charger is a great option for low-power applications. However, a home-automation peripheral such as a high-resolution camera may need a larger battery to increase run times, and such a battery requires a higher-power charger to maintain a short charging time.

High efficiency assumes greater importance as power levels increase. Thus, higher-power chargers are usually switched-mode designs. A switcher can achieve efficiencies well over 90%, but it’s considerably more complicated to design and lay out than its linear counterpart. The flexibility to handle multiple battery chemistries, charging schemes, and configurations is another highly desirable feature. A discrete design, though, usually requires adding a microcontroller with a corresponding increase in complexity. Higher-current switch-mode chargers may also require external power FETs or current-sensing components.

In this area, too, products are available that help integrate functions and simplify the design. The bq25606 is a standalone switch-mode battery-management device that can supply up to 3 A to charge a single-cell Li-ion or Li-polymer battery. The device includes power-path management circuitry that automatically connects the battery to the system if the input power source is removed. The low-impedance power path optimizes switch-mode operation efficiency, reduces battery-charging time, and extends battery life.

5. The bq25606 features high-efficiency operation with internal power FETs, and allows the designer to set parameters with a few external resistors.

The circuit in Figure 5 provides all of the functionality for a typical single-cell charging and system power solution. It also has built-in overvoltage protection to guard against power-line or connection transients.

External resistors set the input current limit, charging current, and battery voltage. Integrated features include an input reverse-voltage blocking FET (Q1); high-side and low-side switching FETs (Q2 and Q3); and battery FET (Q4) between system and battery.

The bq25606 also integrates the bootstrap diode for the high-side gate drive to simplify system design.

The device can manage a wide range of input power sources. USB options include a standard USB host port, USB charging port, and USB-compliant adapter. The device is also compliant with the USB 3.0 power specifications and meets USB On-the-Go (OTG) operation power-rating specifications.

AC-Powered Applications Add Another Battery-Charger Requirement

An ac-powered home-automation application with a backup battery imposes the same requirements on the battery charger as before. However, one more complication arises, since the battery may sit idle for years before being called into service.

During this time, the battery management is connected, but the battery isn’t sourcing any current. In such a “rarely discharged” application, the standard metrics discussed earlier aren’t useful in evaluating the battery’s ability to supply a sudden load current after years of inactivity. The battery can read 100% charge for months or even years according to the standard SoC measurement. The internal impedance does increase over time, but that’s not apparent without measuring current through a load. Furthermore, many rechargeable chemistries show very little change in OCV until the battery’s SoH is well below the replacement point.

The traditional method of making an end-of-service (EOS) determination for a battery is to perform a maintenance cycle: Take the battery offline, discharge a large portion of its capacity (over 90% in some cases), and measure the resulting voltage. If the battery fails, it’s replaced, but of course the battery is unavailable for emergency use during this time.

6. Unlike a standard approach (left), the EOS algorithm in the bq34110 (right) lets the battery remain online during the learning phase. (Source: TI Fully Charged: “How do you detect battery aging in rarely discharged applications?”)

The challenge for designers is how to detect aging without compromising the battery’s availability. Texas Instruments has developed an EOS algorithm that enables an evaluation of the battery status using “learning phases.” The learning phases (Fig. 6) allow the battery to remain in service. They only require a 1-2% discharge to evaluate the health of the battery and estimate if it’s nearing the end of its usable life. Over the multiyear operating life of a backup battery, the EOS algorithm need only run approximately once a month to give sufficient data.

This EOS algorithm is integrated into several battery gas-gauge devices. The bq34110, for example, provides EOS determination for single- and multi-cell batteries up to 65 V. The part supports multiple battery chemistries, including Li-ion and LiFePO₄, nickel metal hydride (NiMH), nickel cadmium (NiCd), and even lead-acid (PbA).

The bq34110’s gas-gauging function uses voltage, current, and temperature data with TI’s Compensated End-of-Discharge Voltage (CEDV) technology to provide SoC and SoH data. The CEDV also estimates the battery’s self-discharge based on its temperature.

The EOS determination function provides an alert when battery capability has degraded and is nearing the end of its useful life. This algorithm can run automatically using an internal timer, or in response to a command from a host microcontroller via its I²C interface. You can find more detail on CEDV and EOS implementations with the bq34110 in this Technical Reference Manual.

Texas Instruments offers several battery fuel gauges with EOS capability, including the bq35100 for non-rechargeable (primary) lithium batteries.

Conclusion

The smart home is here to stay and requires a mix of ac and dc power-management solutions. With Li-ion becoming the battery of choice, the battery charger is a key component. The best choice for a particular application depends on the power level needed, as well as the intended function of the battery: primary or backup power source.

Texas Instruments offers several families of chargers, fuel gauges, and other battery management products to satisfy a wide range of home automation applications.
