TDK Corporation announces the introduction of the TDK-Lambda 30W CCG30G series of DC-DC converters. Operating over a 4:1 input range, these highly efficient products are enclosed in a 1 inch by 1 inch six-sided shielded metal case. Applications include data-communications, tele-communications, process control, broadcast, battery powered and test and measurement equipment.
The CCG30S is available with 3.3V, 5V, 12V or 15V outputs and can operate from either a 9 to 36Vdc or 18 to 76Vdc input. The wide range enables inventory reduction programs as the converters can operate from either 12V and 24V or 24V and 48V nominal inputs without the need to stock two parts.
With operating efficiencies of up to 91%, the CCG30S series will operate in ambient temperatures from -40 to +85°C. All models are backed by a five-year warranty and have a ±10% output trim function, remote on/off and over voltage and over current protection.
The fully isolated CCG series has an input to output isolation of 1,500Vdc and 1,000Vdc input or output to case. Safety certification includes IEC/EN 60950-1, UL/CSA 60950-1 with CE marking for the Low Voltage and RoHS2 Directives.
