(Image courtesy of Aimtec).
Aimtec has introduced the AM1SS-NZ series of DC-DC converters. This new unregulated series of 1-watt power supplies provides continuous short circuit protection with auto recovery restart. The restart feature will work continuously until the short circuit condition is cleared, protecting the converter, the load, and the converter's input circuit from extremely high currents a short circuit can cause.
Supported input voltages of 3.3, 5, 12, 15 and 24VDC convert to single output voltages of 3.3, 5, 9, 12, 15, & 24VDC. Operating within an ambient temperature range of -40°C to +105°C, the AM1SS-NZ series is designed for versatility and can be integrated into a multitude of applications, such as digital circuits, low frequency analog, or relay drive circuits. The series carries a UL 60950-1 certification.
Available in a compact single inline SIP4 package (11.60 x 10.10 x 6.00 mm), the AM1SS-NZ is offered with an input output isolation upgraded to 1500VDC for easy integration in industrial, telecommunication and computer applications.
