The FSL1x series of FPS Green Mode Power Switches from Fairchild Semiconductor helps designers address space-saving, cost-effective solutions for switch mode power supply (SMPS) systems that meet strict energy regulations. The highly integrated FSL1x series is a two-chip-one-package design with an avalanche-rugged 650-800V SenseFET and a current-mode pulse width modulator (PWM) that is specifically designed to reduce component count and system costs for offline SMPS. Additionally, the green-mode functionality of the PWM controller helps to meet global energy regulations by minimizing standby power consumption.
These power switches allow for a longer survival at breakdown mode due to Fairchild's vertical DMOS technology with rugged avalanche characteristics, making them superior to the competitor's designs that utilize lateral DMOS technology. For maximum design flexibility, system productivity and reliability, the FPS family allows for single platform design for various input voltage requirements, so that both domestic and export models can meet all standard passive component requirements.
Compared to other discrete MOSFET and PWM controller solutions, the FSL1x series provides a basic platform ideally suited for significantly reducing total system costs and component count without sacrificing efficiency, productivity and system reliability.
Features:
· Frequency modulation for attenuating electromagnetic interference (EMI)
· Internal soft-start circuit smoothly increases output voltage to help prevent transformer saturation while reducing stress on the secondary diode
· Burst-mode operation to minimize power dissipation in standby mode
· Integrated protection features reduce the need for external components, protections include: overload protection (OLP), over-voltage protection (OVP), thermal shutdown (TSD), abnormal over-current protection (AOCP), output short protection (OSP) auto restart mode
