Ultralow-power switch features ‘deep sleep’ function to hold battery charge
Santa Clara, CA. GLF Integrated Power, a producer of ultralow-power battery-protection ICs for portable and wearable electronics, has introduced the GLF76321 IQSmart IC with a “deep sleep” power-conservation mode. While in this mode, the device operates with a typical standby current of just 7 nA, which is negligible compared with the typical self-discharge of Li-ion batteries. By virtually disconnecting the battery during shipment and storage, the GLF76321 enables products to operate immediately out of the box without the need for recharging.
The prolonged idle state of an electronic product during shipment and storage is one of the major contributors to battery discharge and sometimes of its rechargeable battery’s longevity. Some vendors prefer to ship their products without batteries or to insert a mechanical barrier to prevent discharge. Nevertheless, many products are shipped with batteries pre-installed and charged, the company said, adding that self-discharge for Li-Ion batteries is 5% in first 24 hours and approximately 1 to 2% per month. Without disconnecting the battery, the system leakage can contribute an additional 3 to 5% (and up to 10 % per month) to the discharge. For this reason, most pre-installed battery-powered devices require an initial recharge by the customer upon opening the product. GLF solves this battery-life issue by offering an ultra-low leakage current that is up to 50 times lower than similar devices.
“The GLF76321 IQSmart IC compeletly changes the battery-charging scenario for mobile, wearable, and IoT device OEMs,” said Eileen Sun, president and CEO at GLF Integrated Power. “Now they can store and ship their devices with confidence. The GLF76321’s sleep mode basically disconnects the battery from the system during storage and shipping—and then reconnects and enables operation with a simple push of a button.”
The GLF76321 supports two methods for entering/leaving deep sleep mode. User operation can be initiated or exited by pulling the SRO pin to LOW for a predefined delay, or for logic or interrupt control by a signal to the OFF pin. The GLF76321 includes an integrated 1-ms slew-rate control and output discharge functions. The GLF76X21 family also includes devices with True Power Reset option.
The GLF76x21 is available in 0.97-mm x 1.47-mm x 0.55-mm wafer-level chip-scale package (WLCSP). Price is $0.19 each in OEM quantities.
