USB-C Charger Design First to Deliver 240 W from Single 1C Port

Dec. 27, 2024

A flyback-based switching architecture enables USB-C chargers to generate up to 240 W from a single 1C port.

According to Pulsiv Limited, it’s the first company to offer a solution that delivers 240 W from a single USB-C port. The charger design combines a Pulsiv OSMIUM front-end design with an industry-standard flyback architecture that passes strict EMC/Line Current requirements.

Until now, existing 240-W USB-C charger designs got around the technology’s de facto 140-W maximum limit for a single port by distributing the power across multiple ports. This made using USB-C difficult for many higher power applications such as monitors, gaming laptops, and small domestic appliances. In addition, those earlier Boost PFC+LLC-based designs made EMC compliance challenging, due to their inherently high noise emissions.

Pulsiv solved these problems by using its OSMIUM technology to support a quieter, more efficient flyback architecture that can be used at higher power levels. In addition to reducing the recharge time of portable electronics by up to 80%, it can benefit line-powered applications.

Nick Theodoris, Pulsiv’s Director of Global Sales, said, “Applications such as televisions, monitors, projectors, and games consoles can also benefit from 240-W USB-C power supplies by enabling the power electronics to be removed from the product, significantly reducing their overall size, weight, and cost.”

The company plans to offer three options for deploying the technology:

Reference design: A reference design containing a datasheet, schematic, and bill of materials will be published on www.pulsiv.com in the coming weeks.
Standard assembled module: For those whose resources and time are limited, Pulsiv will offer a standard, fully assembled module with 1x USB-C connector. Pre-orders for samples can be placed now for delivery in late March 2025, with mass-production quantities being delivered from July 2025 onward.
Custom assembled module: For anyone who has more specific requirements, custom assembled modules will also be offered. This flexible option will come with an NRE of just $10,000 and an MOQ of 500 pieces.
